High Strength And Toughness Eccentric Sleeve Castings - 30 Years of Sand Casting Technology Solutions From Densen Group

Densen Group is a specialized manufacturer with over 30 years of experience in large sand mold castings in the 1 to 30 ton weight class.
Today we would like to introduce our eccentric sleeve castings.


1. material selection and performance requirements
High strength and high toughness: use materials such as ZG270-500 and ZG35CrMo to withstand impact loads and crossover stress; alloy compositions such as Cr and Mo are properly adjusted to prevent brittleness and lack of hardness.
Risk of casting defects: Thick-walled sections are prone to shrinkage porosity, so countermeasures must be taken in the design of the hot-press and cold-iron arrangement.


2. difficulty in structural design
Uneven wall thickness: Eccentric structure causes variation in cooling rate, leading to strain and cracking; use fillets with R5mm or more to reduce stress concentration.
Dimensional accuracy: Concentricity of inner and outer diameters and accuracy of keyway position are required, and design must take casting shrinkage into consideration.
3. casting process issues
Hot-metal flow design: Bottom pouring and stairway gating are employed to prevent dripping and slag entrapment.
Core strength: To accommodate complex lumen shapes, resin sand and core bones are used to prevent deformation.
Solidification control: Sequential solidification is promoted, and shrinkage nests are controlled by cold iron and pushing hot water.

Densen Group is a professional manufacturer of large sand molds for 1Ton~30Ton, with more than 30 years of experience.
This day we will introduce our company's eccentric molding products.

1.Material selection and performance requirements
High strength and elasticity: We use ZG270-500, ZG35CrMo and other materials to meet the demand for high strength and elasticity. Adequately adjusting alloy composition such as Cr, Mo, etc., prevent brittleness and lack of hardness.
Risk of defects in construction: Because of the holes that can easily occur in the wall thickness, measures must be taken in the voltage design and cold steel arrangement.

2.Difficulties in structural design
thickness thinness unevenness: because of the eccentricity of the structure, the cooling rate deviation, resulting in deformation and cracking. Fenestration of R5mm or more is recommended to reduce the concentration of application force.
Scale accuracy: Concentricity of inner and outer diameters and accuracy of key tank position are required.

3.Problems with the casting process
Overflow Design: In order to prevent overflow and mill residues, we use bottom pouring and Step feed.
Core strength: Use resin sand and core bone to prevent deformation, and thus to accommodate complex lumen shapes.
Coagulation control:Prompt coagulation by using cold steel to reduce the volume of soup.
